Flat Par QA12XS ADJ LED RC 2 Operation
The ADJ LED RC 2 infrared remote (sold seperately) has many dif-
fernet functions and gives you complete control of your Flat Par
QA12XS. To control the your desired fixture you must aim the con-
troller at the front of the fixture and be no more the 30 feet away. To
use the ADJ LED RC 2 you must first activate the fixtures infrared re-
ceiver, to activate the receiver please see the instructions on page 10.
BLACKOUT - Pressing this button will blackout the fixture.
PROGRAM SELECTION - This button will let you access the units
4 built-in modes; static color mode, color fade mode, color change
mode, and both color fade & color change modes. Each press of the
button will switch to the next running mode.
• When the Red LEDs flash 2 times, this indicates that you are in
Static Color mode. Use the “+” & “-” buttons to scroll through the
static colors, or press two numbers to choose 1 of the 15 static col-
ors. Press FLASH button to activate strobing and use the “+” & “-”
buttons to adjust the flash rate.
Example: Press “0-3” to select static color 3 or press “1-2” to select
static color 12.
• When the Green LEDs flash 2 times, this indicates that you are in
Color Fade & Color Change mode. Press SPEED button and use the
“+” & “-” buttons to adjust the fade/change speed.
• When the Blue LEDs flash 2 times, this indicates that you are in
Color Fade mode. Press SPEED button and use the “+” & “-” buttons
to adjust the color fade speed.
• When the Amber LEDs flash 2 times, this indicates that you are in
Color Change mode. Press SPEED button and use the “+” & “-” but-
tons to adjust the color change speed.
FLASH - This button will activate the strobe effect. You can control
the flash rate by pressing the “+” and “-” buttons. Press this button
again to exit strobe mode.
SPEED - Press this button to activate and use the “+” & “-” buttons
to adjust the speed of color fade and color change mode, color fade
mode, color change mode, and the sound sensitivity level.
DMX MODE - This button will let you select which DMX mode you
ADJ Products, LLC - www.adj.com - Flat Par QA12XS User Manual Page 15
Flat Par QA12XS 2 Channel Mode
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
Flat Par QA12XS 3 Channel Mode
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
3 STROBING
0 - 15 OFF
16 - 255 STROBING SLOW - FAST
Flat Par QA12XS 1 Channel Mode
Channel Value Function
1 COLOR MACROS
0 - 15 OFF
16 - 31 RED
32 - 47 GREEN
48 - 63 BLUE
64 - 79 AMBER
80 - 95 RED & GREEN
96 - 111 RED & BLUE
112 - 127 RED & AMBER
128 - 143 GREEN & BLUE
144 - 159 GREEN & AMBER
160 - 175 BLUE & AMBER
176 - 191 RED & GREEN & BLUE
192 - 207 RED & GREEN & AMBER
208 - 223 RED & BLUE & AMBER
224 - 239 GREEN & BLUE & AMBER
240 - 255 RED & GREEN & BLUE & AMBER
