ADJ Products, LLC - www.adj.com - Element QA User Manual Page 14 ADJ Products, LLC - www.adj.com - Element QA User Manual Page 15
Channel Value Function
8 COLOR MACROS/COLOR CHANGE/
COLOR FADE/SOUND ACTIVITY
0 - 255 COLOR MACRO MODE
Color Macro Chart on pages 22-23
COLOR CHANGE PROGRAMS
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
48 - 63 COLOR CHANGE 4
64 - 79 COLOR CHANGE 5
80 - 95 COLOR CHANGE 6
96 - 111 COLOR CHANGE 7
112 - 127 COLOR CHANGE 8
128 - 143 COLOR CHANGE 9
144 - 159 COLOR CHANGE 10
160 - 175 COLOR CHANGE 11
176 - 191 COLOR CHANGE 12
192 - 207 COLOR CHANGE 13
208 - 223 COLOR CHANGE 14
224 - 239 COLOR CHANGE 15
240 - 255 COLOR CHANGE 16
Element QA 9 Channel Mode
When Channel 7 is between the values of 0-51, Channels 1-4 are used,
and Channel 5 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in Color
Macros Mode, and Channel 5 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in Color
Change Mode, and Channel 9 will control the color change speed.
When Channel 7 is between the values of 154-204, Channel 8 is in Color
Fade Mode, and Channel 9 will control the color fade speed.
When Channel 7 is between the values of 205-255, Channel 8 is in Sound
Active Mode, and Channel 9 will control the sound sensitivity.
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 STROBING
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 PULSE STROBING SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBING SLOW - FAST
224 - 255 LED ON
6 MASTER DIMMER
0 - 255 0% - 100%
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 SOUND ACTIVE MODE
Element QA 9 Channel Mode
