ADJ Products, LLC - www.adj.com - Element QA User Manual Page 16 ADJ Products, LLC - www.adj.com - Element QA User Manual Page 17
Channel Value Function
8 0 - 15 COLOR FADE 1
16 - 31 COLOR FADE 2
32 - 47 COLOR FADE 3
48 - 63 COLOR FADE 4
64 - 79 COLOR FADE 5
80 - 95 COLOR FADE 6
96 - 111 COLOR FADE 7
112 - 127 COLOR FADE 8
128 - 143 COLOR FADE 9
144 - 159 COLOR FADE 10
160 - 175 COLOR FADE 11
176 - 191 COLOR FADE 12
192 - 207 COLOR FADE 13
208 - 223 COLOR FADE 14
224 - 239 COLOR FADE 15
240 - 255 COLOR FADE 16
SOUND ACTIVE PROGRAMS
0 - 15 SOUND ACTIVE MODE 1
16 - 31 SOUND ACTIVE MODE 2
32 - 47 SOUND ACTIVE MODE 3
48 - 63 SOUND ACTIVE MODE 4
64 - 79 SOUND ACTIVE MODE 5
80 - 95 SOUND ACTIVE MODE 6
96 - 111 SOUND ACTIVE MODE 7
112 - 127 SOUND ACTIVE MODE 8
128 - 143 SOUND ACTIVE MODE 9
144 - 159 SOUND ACTIVE MODE 10
160 - 175 SOUND ACTIVE MODE 11
176 - 191 SOUND ACTIVE MODE 12
192 - 207 SOUND ACTIVE MODE 13
208 - 223 SOUND ACTIVE MODE 14
224 - 239 SOUND ACTIVE MODE 15
240 - 255 SOUND ACTIVE MODE 16
Element QA 9 Channel Mode
Element QA 9 Channel Mode
Channel Value Function
9 PROGRAM SPEED/SOUND SENSITIVE
0 - 255 SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
When Channel 7 is between the values of 0-51, Channels 1-4 are used,
and Channel 5 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in Color
Macros Mode, and Channel 5 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in Color
Change Mode, and Channel 9 will control the color change speed.
When Channel 7 is between the values of 154-204, Channel 8 is in Color
Fade Mode, and Channel 9 will control the color fade speed.
When Channel 7 is between the values of 205-255, Channel 8 is in Sound
Active Mode, and Channel 9 will control the sound sensitivity.
