INSTALLATION
KICKSTAND FOR FLOOR PLACEMENT
The Element HEXIP can also be placed on the floor to provide an uplighting display, and features a
retractable kickstand that allows the device to be angled in the direction of the desired display.
To deploy the kickstand, simply toggle the switch on the underside of the device, near the power
charging port (1). The kickstand can then be deployed from the underside (2) at various notched
increments, allowing a maximum angle of 65-90 degrees from the vertical axis (3).
1 2
3
Angle Range:
65 deg to 90 deg
