CHANNEL
DMX
VALUES
FUNCTION
6 CH 7 CH 8 CH 11 CH 12 CH
1 1 1 1 1 000-255 RED, 1~100%
2 2 2 2 2 000-255 GREEN, 1~100%
3 3 3 3 3 000-255 BLUE, 1~100%
4 4 4 4 4 000-255 WHITE, 1~100%
5 5 5 5 5 000-255 AMBER, 1~100%
6 6 6 6 6 000-255 UV, 1~100%
7 7 7 7 000-255 MASTER DIMMER, 1~100%
8 8 8
STROBING/SHUTTER
000-031 LED OFF
032-063 LED ON
064-095 STROBING SLOW-FAST
096-127 LED ON
128-159 PULSE STROBING SLOW-FAST
160-191 LED ON
192-223 RANDOM STROBING SLOW-FAST
224-255 LED ON
9 9
PROGRAM SELECTION MODE
000-051 RGBWA+UV DIMMING MODE
052-102 COLOR MACRO MODE
103-153 COLOR CHANGE MODE
154-204 COLOR FADE MODE
205-255 SOUND ACTIVE MODE
DMX TRAITS
NOTE: 11 CHANNEL DMX MODE & 12 CHANNEL DMX MODE:
When Channel 9 is between the values of 0-51, Channels 1-6 are used, and Channel 8 will
control strobing.
When Channel 9 is between the values of 52-102, Channel 10 is in Color Macros Mode, and
Channel 8 will control strobing.
When Channel 9 is between the values of 103-153, Channel 10 is in Color Change Mode, and
Channel 11 will control the color change speed.
When Channel 9 is between the values of 154-204, Channel 10 is in Color Fade Mode, and
Channel 11 will control the color fade speed.
When Channel 9 is between the values of 205-255, Channel 10 is in Sound Active Mode, and
Channel 11 will control the sound sensitivity.
