ADJ FLAT PAR TW5 - Warranty Registration; Installation

ADJ Products, LLC - www.adj.com - Flat Par TW5 User Manual Page 3
• Mulit-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 6 DMX Modes: 2 Channel Mode, 3 Channel Mode, 4 Channel
Mode, 5 Channel Mode, 8 Channel Mode and 9 Channel Mode.
• ADJ LED RC3 compatiable (Not Included)
• Power Cord Daisy Chain (See page 21)
Flat Par TW5 Warranty Registration
Flat Par TW5 Features
The Flat Par TW5 carries a 2 year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All pack-
ages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
Flat Par TW5 Installation
Flat Par TW5 Introduction
ADJ Products, LLC - www.adj.com - Flat Par TW5 User Manual Page 2
Unpacking: Thank you for purchasing the Flat Par TW5 by American
DJ®. Every Flat Par TW5 has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact-
ing customer support.
Introduction: The ADJ Flat Par TW5 is part of a continuing pursuit
to create high quality intelligent lighting. The Flat Par TW5 is a DMX
intelligent, high powered LED par fixture. This xture can be used in
a stand alone mode or connected in a Master/Slave conguration.
This wash has five operating modes: Sound Active mode, Auto mode,
RGB mode, Static Color mode, and DMX control mode. To optimize
the performance of this product, please read these operating instruc-
tions carefully to familiarize yourself with the basic operations of this
unit. These instructions contain important safety information regarding
the use and maintenance of this unit. Please keep this manual with the
unit, for future reference.
Customer Support: American DJ provides a customer support line, to
provide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.ADJ.com for any comments or suggestions. Ser-
vice Hours are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic
Standard Time.
Voice: (323) 582-3322
Fax: (323) 582-3108
E-mail: support@AmericanDJ.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ.
PLEASE recycle the shipping carton when ever possible.
