Starbar Wash Installation
The unit can be mounted using mounting clamps (not provided), axing them to either the mount-
ing brackets that are provided with the unit or the rigging points located at the top of the bar. Always
ensure that the unit is rmly xed to avoid vibration and slipping while operating. Always ensure
that the structure to which you are attaching the unit is secure and is able to support a weight of
10 times the unit’s weight. When hanging the unit by the rigging points or brackets, always use and
install a safety cable as a safety measure to prevent accidental damage and/or injury in the event the
clamp fails. The equipment must be installed by a professional, and it must be installed in a place
where it is out of the reach of people’s grasp.
Bracket Bracket
Rigging Point
(M10 Bolt)
Rigging Point
(M10 Bolt)
OVERHEAD INSTALLATION
