ADJ Products, LLC - www.adj.com - Starbar Wash User Manual Page 8
17
18
21
19
20
21
21
20
20
Starbar Wash Overview
17. Center Adjustment Knob
18. Locking Pin
19. Base/Leg Adjustment Knob
20. 3 x Tripod Legs
21. 3 x Tripod Stays
22. Left Foot Pedal
23. Right Foot Pedal
