ADJ Products, LLC - www.adj.com - VBar Pak User Manual Page 10
ADJ Products, LLC - www.adj.com - VBar Pak User Manual Page 11
Master-Slave Operation:
This function will allows you to link units together to run in a Master-Slave
configuration. In a Master-Slave configuration one unit will act as the
controlling unit and the others will react and copy the controlling units
operation. Any unit can act as a Master or as a Slave however, only one
unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Connect the rst “Slave” unit to the “Master.”
3. Set the “Master” unit to your desired mode of operation. The “Slave”
unit will now follow the “Master”.
VBar Pak Master-Slave Configuration VBar Pak Operating Instructions
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLXX” is dis-
played.
2. There are 15 colors to choose from. Use the UP and DOWN buttons
to scroll through the 15 colors. After you have found your desired
color you can activate strobing by pressing the SET UP button to
enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the MODE
button to exit.
Infrared Receiver:
This function is used to activate and deactivate the infrared receiver.
When this function is activated you can control the fixture using the ADJ
LED RC 2 (Remote Control). Please see the next page for ADJ LED RC 2
controls and functions.
1. Plug the fixture in and press the MODE button until “dXX” is displayed.
“XX” represents either “on” or “oFF”.
2. Press the SET UP button until “IrXX” is displayed. “XX” represents
either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
