ADJ Products, LLC - www.adj.com - VBar Pak User Manual Page 16 ADJ Products, LLC - www.adj.com - VBar Pak User Manual Page 17
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
VBar Pak 5 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
VBar Pak 4 Channel Mode
Channels 1, 2, & 3 will not work, when Channel 6 is being used.
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 COLOR MACROS
0 - 255 PLEASE SEE 1 CHANNEL MODE
VBar Pak 6 Channel Mode
Channels 1, 2, & 3 will not work, when Channel 7 is being used.
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 - 15 OFF
16 - 255 SLOW - FAST
7 COLOR MACROS
0 - 255 PLEASE SEE 1 CHANNEL MODE
VBar Pak 7 Channel Mode
