4.4 The PRINT Menu
Press the
<PRINT>
key
with th
e LCD
in
the Li
ve Indicatin
g mod
e to enter
th
e PRINT
Menu.
USB Host Menu will
be di
splayed prior
to
display
of
menu
o
ptions
b
elow.
Use
th
e
<ARROW>
keys
to
scroll
to
other
menu
items.
Use
the
n
umber
keys
to
select
options.
The
following functions are provided in the PRINT Menu.
1) XY Data-> Host - Transmit XY Data via the USB port to a remote computer running GaugeSafe.
2) Stored Res-> Host - Transmit stored test results and statistics via the USB port to a remote computer running GaugeSafe.
3) Test Method -> Host - Transmit Test Method settings to computer running GaugeSafe.
4) Calibration -> Host - Transmit calibration data to computer running GaugeSafe.
If the optional USB port is included on the controller a secondary set of options will appear for transfering to a flash drive.
4.5 The UTILS Menu
Press the <UTILS> key with t
he LCD in the Liv
e Indicating mode to
enter the UTILS
Menu.
Use the <ARROW> key
s to scroll to oth
er
menu items. Use the number keys to select options. The following functions are provided in the UTILS Menu.
1) Clear Results - Clear all stored results for the active test method or for all test methods.
2) Store - Set to store test results automatically or manually
3) Set Date/Time - Set the eP2 Controller's date and time clock.
4) Stiffness Factor- Enter a value for machine compliance. Compensates logged and transmitted position data based on load. Set to
zero to disable stiffness correction.
5) Install Defaults (password protected) - Reset the eP2 Controller to its default state. If defaults are installed, all test setup
information must be reentered. Password required.
6) Diagnostics - view analog channel and digital I/O information.
7) Transducer - Calibrate the load and position channels and set the maximum speed for the position channel. The load channel can
also be calibrated from the Zero Menu. The calibration menu is password protected. The shunt calibration is used to span the load
calibration. See Section 5.0 for calibration instructions.
8) Supervisor (password protected) - Toggles Supervisor ON/OFF. When Supervisor is ON changes can be made to the settings of the
Test Methods and Calibration. When Supervisor is OFF changes cannot be made to Test Methods or Calibration, but the
previously stored Procedures can be selected via the Test Method key.
