3.0. The Keys
3.1 The <Home> Key
Sends the crosshead to specified home location
3.2 The <STORE> Key
The STORE key writes the current test result to permanent memory. Results are stored according to Test Method. Up to 50 results
can be stored per test method. All results stored to memory downloaded to a remote computer running GaugeSafe Basic, Plus, or
Live software.
3.3 The <ENTER/Start> Key
• Accepts /assigns the value in a data entry field to that field.
• Initiates a menu function. For example: If the screen displays PRN CURRENT TEST, pressing <ENTER> will cause the current test
results to be printed.
• Turns ON/OFF a menu option.
• Starts new test when controller in ready status.
3.4 The <ESC/STOP> Key
• Returns the LCD to the Live Indicating mode from any menu.
• Clears a data entry mistake by restoring the original number in a data entry field.
• Stops Test and Crosshead movement when machine in testing mode.
3.5 The <Jog UP & Jog Dn> Keys
• Move up and down between selections in menu when in menu view.
• Jog crosshead up and down at user specified rate when display is on live screen.
3.4 The <Freeze> Key
• Freeze the strain channel (Strain Channel optional)
3.6 The ID# Key
The ID# key is used to set the Specimen ID# and specify specimen dimensions.
This key is only active when the LCD is in the Live Indicating mode.
3.7 E-STOP (RED BUTTON ON TOP OF UNIT) - Emergency Stop
Stops cross head movement.
