6 System features
6.1 General LED status displays
The integrated LEDs indicate the status of the various interfaces. This makes diagnosis possible at the
installation site.
LED status Representation
Off
Illuminates green
Flashes green
Illuminates red
Illuminates orange
Flashes orange
