8 Technical data
IRF1000 series
Operating system Embedded LinuX
Configuration protocol http, https
Interfaces 1 x WAN RJ45 (10/100 Mbit/s Autocrossover)
3 x LAN RJ45 (10/100 Mbit/s Autocrossover)
1 x digital input (electrically isolated)
1 x RS-485 for Modbus RTU (electrically isolated)
External device
dimensions
See dimensional drawings in chapter 5
Weight Approx. 0.2 kg
Protection class IP30 (tested by ADS-TEC, not evaluated by UL)
Over voltage category I as per DIN EN 60664-1 (max. 1500 V)
Pollution degree 2 as per IEC 61010-1
Altitude during operation 2000 m or less
Power supply Voltage: 24 VDC ± 20 %
Requirements on the power adapter:
• Class PS2 acc. to IEC 62368-1 – or –
Limited Power Source (LPS) acc. to IEC 60950-1
• Short-circuit current: < 8 A
• For devices with UL-Certification: NEC Class 2
Max. current
consumption
IRF1401: 0.5 A (≙ 12 W @ 24 V)
IRF1421: 0.8 A (≙ 19.2 W @ 24 V)
Ambient temperature in operation -30 … +70°C
for storage -40 … +85°C
You can find further information about the device in the data sheet on our website:
http://www.ads-tec.de
