7 Commissioning
7.1 Initial configuration
Recommendation for use:
For the initial configuration, a connection to a PC is required.
Connecting the 24 VDC power source
The device can be supplied via a 24 VDC power source. The corresponding plugs are included in the
scope of delivery (4-pin plugs).
Connect the device with the appropriate power source.
Connecting the RJ45 network cable
When placing into operation for the first time, a connection is required between the device and a PC via
an RJ45 network cable.
Connect the device to a PC:
Device LAN connection  PC LAN connection
