ADTECH9 Series CNC Programming Manual
(1) Instruction of returning to reference point
(2) If G53 instruction is used, basic mechanical coordinate system selection will become temporary
compensation vector.
When the coordinate system sets (G92) instruction, the compensation vector doesn’t change.
Details
In the following segments, the tool doesn’t have motion
M03;…………………………………M instruction
S12;………………………………...S instruction
T45;………………………………….T instruction
G04X500;……………………………Pause
G22X200 Y150 Z100;……………………Restricted processing area setting
G10 L10 P01 R50;………………………..Compensation setting
G92 X600 Y400 Z500;……………………Coordinate system setting
(G17)Z40;……………………………..Compensation the motion out of the plane
G90;……………………………………..G instruction only
G91 X0;…………………………………… 0 is moved
M00, M01, M02, M03 stop M instruction
