ADTECH9 Series CNC Programming Manual
(3) G38 I_J_(K_) instruction and G41/G42 I_J_(K_) instruction specified different vectors.
(4) According to the combination of G41/G42 and I, J, K instructions, the compensation method follows:
G41/G42
I,J,K
Compensation method
No
No
Intersection caculstion vector
No
Yes
Intersection caculstion vector
Yes
No
Intersection caculstion vector
Yes
Yes
I, J vector, no segment inserted
