ADTRAN 600 Series User Manual

Total Access 600 Series SHDSL IAD User Interface Guide/64200683L1-31B
Page 53
© 2002, ADTRAN, Inc. Total Access 600 Series User Manual
The following settings are used for FRF8.
L
AN
FR M
AINT
P
ROTOCOL
Frame Relay maintenance or signaling protocol
between local V.35 port and the attached DTE
port, support ANSI Annex A, CCITT Q933 An-
nex D, CISCO LMI or Static (no signaling).
L
AN
FR P
OLL
T
IMEOUT
T392 (5-30)
T392 for signaling protocol, typical value 15. No
meaning if Maint Protocol is Static.
F
R
/ATM PVC M
APPING
Up to 4 mappings are supported.
FR DLCI
Frame Relay DLCI on V.35 port.
ATM VPI
Specifies the virtual path to which DLCI is
mapped.
$709&,
Specifies the virtual circuit to which DLCI is
mapped.
T
RANSLATE
Translate or transparent mode between
Frame Relay frames and ATM cells.
'
(
0
$3
Map Frame Relay DE bit to ATM CLPI bit,
Always 0, Always 1 or Convert each other.
)
(&1
0
$3
Map Frame Relay FECN bit to ATM EFCI
bit, Always 0, Always 1 or Convert each
other.
