ADTRAN DE-4E - Figure 9. Performance History Screen; Figure 10. Loopback Options Screen

10 Section 61245207L2-5, Issue 3 61245207L2-5C
The Performance History Screen displays 15-minute
and 24-hour registers for several points in the circuit.
Figure 9 depicts the Performance History Screen.
Figure 10. Loopback Options Screen
LOOPBACK OPTIONS
FT1-DP FNID
_____ _____
| | | |
| | | |
--->| | | |<---
| | | |
NET | |<===========================>| | CUST
| | | |
<---| | | |--->
| | | |
| | | |
|_____| |_____|
1) LOOPBACK TO NETWORK AT FT1-DP =INACTIVE
2) LOOPBACK TO CUSTOMER AT FT1-DP =INACTIVE
3) LOOPBACK TO NETWORK AT FNID =INACTIVE
4) LOOPBACK TO CUSTOMER AT FNID =INACTIVE
Press corresponding number to toggle loopback option.
Press “M” for Main Menu.
Figure 9. Performance History Screen
PERFORMANCE HISTORY <VIEW 2 - FNID DS1 RECEIVER>
24 HOUR REGISTERS 15 MINUTE REGISTERS
---ES---SES-- --ES-SES-----------ES-SES-
00000 00000 <---CURRENT---> 000 000
-1: ----- ----- <-- --> -1: --- --- -17: --- ---
-2: ----- ----- | | -2: --- --- -18: --- ---
-3: ----- ----- | | -3: --- --- -19: --- ---
-4: ----- ----- | | -4: --- --- -20: --- ---
-5: ----- ----- |PREVIOUS | -5: --- --- -21: --- ---
-6: ----- ----- | | -6: --- --- -22: --- ---
-7: ----- ----- <-- | -7: --- --- -23: --- ---
| -8: --- --- -24: --- ---
VIEW LOCATION DIAGRAM | -9: --- --- -25: --- ---
| -10: --- --- -26: --- ---
-->|F| |F|--> | -11: --- --- -27: --- ---
|T| |N| | -12: --- --- -28: --- ---
|1|<-3-------DSL-----4->|I| | -13: --- --- -29: --- ---
|D| |D| | -14: --- --- -30: --- ---
<--|P| | |<-2 | -15: --- --- -31: --- ---
--> -16: --- --- -32: --- ---
Press view number to select view, “M” to return to Main Menu
Figure 10 depicts the FT1 DP Loopback Options
Screen. Loopback may be initiated or terminated
using this screen. A status of current loopback
conditions also appear.
