3.3.1 Loops
For Multi-loop panels only – On selecting the LOOPS option, the display will prompt for the loop to be viewed /
programmed. E.g. for the Mx-4400: -
[Select Loop]
1
st
-Loop 2
nd
-Loop 3
rd
-Loop 4
th
-Loop
  x x
The list of loops available will be adjusted automatically to show only those loops that have a loop driver card
installed. In the above example, loop drivers are installed in positions 1 and 2.
Press the  buttons to scroll through the list of loops available and then press the ✔ button to select the
loop required.
The display will then show a list of programming options as follows: (Note: On selecting the LOOPS option on
the Mx-4100, this display will be shown directly).
[Loop 1]
VIEW/EDIT AUTO LEARN CALIBRATE
DRIVER
3.3.2 Loops – View/Edit
The VIEW/EDIT option shows a list of the devices connected to the loop learnt by the panel. For example:
[Loop 1] More>
Address State Type Value
001.0 Normal CALL POINT 16
002.0 Normal MULTI.SENSOR 28
003.0 Normal ION SMOKE 23
004.0 Normal HEAT 21
The first device on the loop is shown at the top of the list and is highlighted. Press the  buttons to scroll
through the list of devices.
Press the  buttons to view additional information. The display highlights a particular parameter. To change
the value of this parameter (if not view only), press the ✔ button and appropriate options will be shown on the
display.
3.3.2.1 State
This parameter shows the current operational status of the device. For example, this can show Normal, Fire
Alarm, Device Missing, etc.
This parameter cannot be changed.
3.3.2.2 Type
This parameter shows the type of device learnt by the panel. For example, this can show Call Point, Multi-
Sensor, ION Smoke, Heat, etc.
This parameter cannot be changed.
