6.3 Private internal access across an existing LAN where
external email notifications are required
Using “Site A” as an example the configuration settings for the ipGateway would be:
ipGateway Setting
Value
IP Address
192.168.0.100
Subnet Mask
255.255.255.0
SMTP Server
192.168.0.20
SMTP Username
myaccount@company.co.uk
SMTP Password
myemailpassword
Email Address
myipgateway@company.co.uk
Admin Password
MyAdminPwd
User Password
MyUserPwd
All other configuration settings can be left as default.
6.3.1 Configuration elsewhere on the network
6.3.1.1 Email Server
The email server must be configured to allow “Email Relaying” from IP Address 192.168.0.100 (i.e. the
ipGateway)
6.4 Public access across the Internet where external email
notifications are not required
Using “Site A” as an example the configuration settings for the ipGateway would be:
ipGateway Setting
Value
IP Address
192.168.0.100
Subnet Mask
255.255.255.0
Gateway
192.168.0.4
Admin Password
MyAdminPwd
User Password
MyUserPwd
All other configuration settings can be left as default.
6.4.1 Configuration elsewhere on the network
6.4.1.1 Router NAT (Port Forward)
In addition to the ipGateway configuration, a NAT (Port Forward) will need to be setup on the router
(192.168.0.4) to provide an external to internal address translation, i.e.
External Port
Internal Port
Internal IP Address
80
80
192.168.0.100
This will allow a user on “Site B” to type the following into the address bar of his browser to gain access to the
ipGateway at “Site A”:
http://74.125.230.148
