Specifications:
Models, Sales Order Parts:
Mxp-035 : 4-Way Programmable Relay Card
Mxp-035-BXP : 4-Way Programmable Relay Card Boxed with 1A PSU
Applications / Limitations:
Plant Control and Signalling relay outputs.
Each output can be assigned to an individual output group and is fully programmable for any output function
allowed within the configuration program.
Only one 4 Way Relay Output Card can be fitted within an control panel.
Fitting of the Mxp-035 in an MxPro 4 panel precludes fitting of other panel input or output cards. See panel
manuals for further information.
Can be used with MxPro 4, MxPro 5 and Axis EN Panels.
4200, 4400 and 4800 control panels programmed with Version 021-03 software (or later) and fitted with base
card hardware revision levels 10 (712-1022 Mx-4400) and 09 (712-1022-002 Mx-4200) or later.
Compatible with the PC Configuration Tool from version 4.7 or later.
Requires installation of the Mxp-031 Peripheral Bus Interface Adaptor card in the panel.
EN54-2: 1997, BS EN54-4: 1997
95% non-condensing (maximum)
Steel, IP30, RAL9002, 320 mm high x 345 mm wide x 88 mm deep, 3kg (excluding
batteries)
230V AC, 50Hz (+10%, -15%) FUSE T3.15H250
2x12V, 7AH Sealed Lead-Acid Type (Yuasa recommended)
Power and General PSU Fault – Separate indications of specific PSU fault conditions
are available on the PSU.
110 mm x 86 mm x 18 mm, 130 grams
24VDC nominal (18-28VDC),
(quiescent) 22mA (all outputs on) 75mA typical, 100mA maximum
Relay Circuit ON, Communications TX & RX and Heartbeat
230V AC, 5A resistive / 230V AC, ½ HP / 30VDC, 5A
30VDC, 1A when mounted on panel chassis
Minimum 20mA wetting current
150Ω (applied via “485 term” jumper – see section 2.6.3)
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
