ANCILLARY CIRCUIT BOARDS
QZXL-HSZEC High spec 4 zone extension card
QZXL-ZEC Std spec 4 zone extension card
4 x conventional or Twin Wire
zone circuits
4 x conventional or Twin Wire
zone circuits
2 x switched ve outputs
1 x Aux relay output
2 x monitored sounder circuits
Piggy backs on Main PCB for
connection to repeater panels
6 programmable switched ve
outputs
TPCA05 Comms PCB
