1.1 Introduction
This manual will discuss in detail the specifications, functions and application wiring
of the ADAM-5000 series of I/O modules. To organize an ADAM-5510 Series
Controller, you need to select I/O modules to interface the main unit with field
devices or processes that you have previously determined. Advantech provides the
following types of ADAM-5000 I/O modules for various applications so far. Following
table is the I/O modules support list we provided for user’s choice.
Table 1.1: Supported I/O Module List
Module Name Specification Reference
Analog I/O
ADAM-5013 3-ch RTD input Isolated
ADAM-5017 8-ch AI Isolated
ADAM-5017P 8-ch AI with independent Input Isolated
ADAM-5017H 8-ch High-speed AI Isolated
ADAM-5017UH 8-ch Ultra High-speed AI Isolated
ADAM-5018 7-ch Thermocouple input Isolated
ADAM-5018P 7-ch Thermocouple input with
independent Input
Isolated
ADAM-5024 4-ch AO Isolated
Digital I/O
ADAM-5050 16-ch DI/O Non-isolated
ADAM-5051 16-ch DI Non-isolated
ADAM-5051D 16-ch DI w/LED Non-isolated
ADAM-5051S 16-ch Isolated DI w/LED Isolated
ADAM-5052 8-ch DI Isolated
ADAM-5053S 32-ch Isolated DI Isolated
ADAM-5055S 16-ch. Isolated DI/O w/LED Isolated
ADAM-5056 16-ch DO Non-isolated
ADAM-5056D 16-ch DO w/LED Non-isolated
ADAM-5056S 16-ch Isolated DO w/LED Isolated
ADAM-5056SO 16-ch Iso. DO w/LED (source) Isolated
ADAM-5057S 32-ch Isolated DO Isolated
Relay Output
ADAM-5060 6-ch. Relay output Isolated
ADAM-5069 8-ch Relay output Isolated
Counter/
Frequency
ADAM-5080 4-ch Counter/Frequency Isolated
ADAM-5081 4-ch High Speed Counter/Frequency Isolated
Serial I/O
ADAM-5090 4-port RS232 Non-isolated
ADAM-5091 4-port RS232/422/485 with Share
Interrupt
Non-isolated
ADAM-5095 2-port CAN Isolated
Storage
ADAM-5030 2-slot SD Storage Module Non-isolated

Advantech ADAM-5017 Specifications

General

Brand	Advantech
Model	ADAM-5017
Category	I/O Systems
Language	English
