ICAM-520/500 User Manual 38
Please setup the ICAM-500 with the following instructions to operate ICAM-500 in
local mode for troubleshooting. If the user has problems connecting the ICAM-500
via a host PC, or if ICAM-500 still can’t boot up and make an acquisition after reset
up the ICAM-500, contact Advantech FAE for technical support.
5.1 Connection for Keyboard, Mouse and Display
 Insert the USB type C adapter/cable to USB type C connector directly for key-
board & mouse connection.
 Insert the HDMI cable to connector directly for display connection.
5.2 Reconnect a Power and D I/O Cable
 Align the alignment pin (Cable side) with the alignment channel (Device side).
 Inset the cable connector and tighten the threaded collar to fix the connection.
 Plugin the power source after the M12 connector is fastened on the ICAM-500.
5.3 Operate the Camera Function
1. Use Google Chrome on the desktop to connect with the ICAM-500.
2. Enter the default IP address of the ICAM-500: 192.168.0.100:5000 or Local-
host5000
3. ICAM-500 web server interface will be displayed in the Chrome browser.
5.4 BSP Image Flashing
1. Connect ICAM-500 device and Host PC(X 86 with Ubuntu OS) with micro USB
cable and connect the HDMI screen to the ICAM-500 device.
