1. Product Overview 1.7 Mounting Recommendations
1.7 Mounting Recommendations
The router can be placed:
• on a flat surface,
• on a DIN rail EN 60715 with the metal DIN rail clip (see Chapter 1.8)
For most applications with a built-in router within a switchboard, it is possible to recognize two kinds of
environments:
• A non-public, industry environment of low voltage with high interference,
• a public environment of low voltage and without high interference.
For both of these environments, it is possible to mount the router to a switchboard, after which there is
no need to have examination immunity or issues in connection with EMC according to EN 61439-1:2011.
In compliance with the EN 61439-1:2011 specification, it is necessary to observe the following as-
sembly instructions for a router attached to a switchboard:
• For whip antennas it is recommended to observe a minimum distance of 6 cm from cables and metal
surfaces on every side in order to avoid interference. When using an external antenna separate from
the switchboard it is necessary to fit a lightning conductor.
• When mounting a router on sheet-steel we recommend using a cable antenna.
• For all cables, we recommend to bind the bunch, and for this we recommend:
– The length of the bunch (the combination of power supply and data cables) should be a max-
imum 1.5 m. If the length of data cables exceeds 1.5 m or if the cable is leading towards the
switchboard, we recommend installing surge protectors.
– Data cables must not have a reticular tension of ∼ 230 V/50 Hz or ∼ 120 V/60 Hz.
• Sufficient space must be left between each connector for the handling of cables,
• To ensure the correct functioning of the router we recommend the use of an earth-bonding distribution
frame for the grounding of the grounding screew, see Chapter 2.3.
ICR-2701 Hardware Manual (preliminary version) 8
