4. Technical Specifications 4.3 Type Tests and Environmental Conditions
4.3 Type Tests and Environmental Conditions
Phenomena Test Description Test levels
ESD EN 61000-4-2 Enclosure CD ±6 kV, L3
AD ±8 kV, L3
RF field AM
modulated
EN 61000-4-3 Enclosure 20 V/m, 80 MHz – 1 GHz, LX
10 V/m, 1 GHz – 6 GHz, L3
Fast transient EN 61000-4-4 DC
ETH - FTP
AC/DC
±1 kV, 5/50Tr/Th ns, 100 kHz, L2
±1 kV, 5/50Tr/Th ns, 100 kHz, L3
±2 kV, 5/50Tr/Th ns, 100 kHz, L3
Surge EN 61000-4-5 DC
ETH
AC/DC
±1 kV,1,2/50(8/20) Tr/Th us L2
±1 kV,1,2/50(8/20) Tr/Th us L2
±2 kV,1,2/50(8/20) Tr/Th us L3
RF conducted EN 61000-4-6 DC
ETH
AC/DC
10V,0.15-80MHz,80% AM(1kHz),L3
10V,0.15-80MHz,80% AM(1kHz),L3
10V,0.15-80MHz,80% AM(1kHz),L3
Dips &
interruptions
EN 61000-4-11 AC/DC dip 0% 0,5cycle, 0% 1 cycle, 70% 25
cycles, interuption 0% 250 cycles
Radiated emission EN 55032 Enclosure
DC
ETH
AC/DC
Cl. B,30MHz-1GHz,1GHz-6GHz
Class B, 150 kHz – 30 MHz
Class B, 150 kHz – 30 MHz
Class B, 150 kHz – 30 MHz
Table 11: Type Tests and Environmental Conditions
