4. Technical Specifications 4.4 Parameters of WiFi
4.4 Parameters of WiFi
Parameter Description
Supported Standards IEEE802.11 ac/a/b/g/n 2.4 GHz / 5 GHz
Antenna connector 1x RP-SMA
Input impedance: 50 Ω
Data Rate 802.11b: 1, 2, 5.5, 11Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: Max. 72 Mbps @ 20 MHz channel
802.11n: Max. 150 Mbps @ 40 MHz channel
Frequency Ranges 2.4 GHz ISM Bands 2.412-2.472 GHz
5.15-5.25 GHz (FCC UNII-low band) for US/Canada and EU
5.25-5.35 GHz (FCC UNII-middle band) for US/Canada and EU
5.47-5.725 GHz for EU
5.725-5.825 GHz (FCC UNII-high band) for US/Canada
Modulation DSSS, OFDM, DBPSK, DQPSK, CCK, 16-QAM, 64-QAM
2.4 GHz Channels 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
5 GHz Channels 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108, 112,
116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161, 165
Type of Device Access point (AP) (up to 8 clients)
Station (STA)
Multirole (STA&AP)
Security – Standards WPA, WPA2, WPA3, 802.1X
Security – Encryption WEP, TKIP, AES
TX Power Max. 18 dBm @ 2.4 GHz
Max. 15 dBm @ 5 GHz
Table 12: Technical Parameters of WiFi
ICR-2701 Hardware Manual (preliminary version) 21
