Advantech MIC-770 V2 User Manual

3 MIC-770 V2 User Manual
Chapter 1 General Introduction
1.2.2 Display
 Chipset:
– W480E: Intel
®
HD Graphics 630, supports DirectX 12
– H420E: Intel
®
HD Graphics 610, supports DirectX 12
 Resolution:
– VGA: Supports up to 2048 x 1152 @ 60 Hz
– HDMI: Supports up to 3840 x 2160 @ 30Hz
1.2.3 Ethernet
 Controller:
– W480E LAN1: Intel
®
I219LM, LAN2: Intel
®
i210IT (supports iBMC)
– H420E LAN1: Intel
®
I219V, LAN2: Intel
®
i210IT
 Speed: 10/100/1000 Mbps
 Interface: 2 x RJ45
 Standard: Compliant with IEEE 802.3, IEEE802.3u, IEEE 802.ab.
1.2.4 SUSI API
MIC-770 V2 supports SUSI API which helps customers to develop their own remote
management programs under Windows 10.
1.2.5 WISE-iBMC Out-of-band Power Management
 MIC-770 V2 W480E SKU is equipped with WISE-iBMC solution which pro-
vides out-of-band management for remote power-on/power-off/reset/
force-shutdown via LAN2 if abnormal conditions are selected.
Note! WISE-iBMC power control function is operated on Advantech WISE-
DeviceOn software. Before installation and setup of WISE-Agent pro-
gram, changing device IP address to the same as your network IP via a
utility tool is necessary. Please refer to product support website to down-
load iBMC utility, DeviceOn software, and SOP/user manual.
