Advantech MIC-770 V2 User Manual

MIC-770 V2 User Manual 4
1.3 Chipset
1.3.1 Functional Specification
1.3.1.1 Processor
1.3.1.2 Chipset
Processor
Intel
®
10th Gen Xeon/Core i CPU socket (LGA1200) (Xeon support by
W480E SKU only)
PCH
 Intel
®
W480E/H420E chipset
Memory
 Supports DDR4 2666/2933 MHz ECC RAM (W480E SKU only)
(without ECC)
 SODIMM Socket:
– 260-pin SODIMM socket*2 (up to 32GB per socket)
Chipset
integrated Intel
HD Graphic
 Intel
®
HD Graphics 630/610
 Supports DirectX 12
 Supports OpenGL 4.4
 Supports Intel
®
Quick Sync Video
 IO interface
– VGA: Supports resolutions up to 2048 x 1152 @ 60 Hz
(VGA connector: On-board D-SUB 15P)
– HDMI: Supports resolution up to 3840×2160 @30Hz
(HDMI Connector: On-board HDMI)
SATA Interface
 3 x SATA3.0 (W SKU), 2 x SATA3.0 (H SKU)
 Legacy IED (Including IRQ)/Native AHCI appearance to OS
 Partial/slumber power management modes with wake
 Capable of 6Gbit/s transfer rate
USB Interface
 W480E: 2 x USB3.2 (Gen.2) , 6 x USB3.2 (Gen.1)
 H420E: 4 x USB 3.2 (Gen.2) and 4 x USB 2.0
 Supports high-speed, full-speed, and low-speed capable
 Supports legacy keyboard/mouse software
Power
Management
 Supports ACPI 5.0
 ACPI Power Management Logic supported
 Power Connector: plug-in block 4Px1
BIOS  AMI 256Mb (W SKU)/128Mb (H SKU) Flash BIOS via SPI
Note! Legacy platform is not supported.
