Advantech MIC-770 V2 User Manual

5 MIC-770 V2 User Manual
Chapter 1 General Introduction
1.3.1.3 Others
Serial ports
Nuvoton NCT 6106D supported
 Up to 6 serial ports by Nuvoton NCT6106D supported
 High speed NS16C550A compatible UARTs with date rates to 1.5
Mbps
 Supports IRQ sharing among serial port
 COM1/2: Supports RS-232/422/485 and setting mode by BIOS and
supports auto flow control
 COM 3~6: Support for RS-232, via optional cable
Serial ports connector: D-SUB CON.9P
LAN
W480E LAN1: Intel
®
I219LM (PHY), LAN2: Intel
®
i210IT I210IT (NIC)
(Support iBMC)
H420E LAN1: Intel
®
I219V (PHY), LAN2: Intel
®
i210IT I210IT (NIC)
 Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.ab.
 Supports 10/100/1000 Mbps
 Supports Wake on LAN
Audio
Audio Codec: Realtek ALC888:
 Compliant with HD Audio specifications
 Supports to 16/20/24-bit DAC and 16/20/24-bit ADC resolution
 Supports: Line-out, Mic-in
 DAC supports 16/20/24-bit PCM format, multiple stereo recording
Industrial
Features
Watchdog timer:
 Can generate system reset or NC. The watchdog timer is program-
mable, with each unit equal to one second (255 levels).
Battery backup  BR2032 3 V/190mAh
