19 PCI-1756 User Manual
Chapter 3 Signal Connections
3.2.1 Board ID (SW1)
The PCI-1756 have a built-in DIP switch (SW1), which is used to define each card’s
board ID. When there are multiple cards on the same chassis, this board ID switch is
useful for identifying each card’s device number. After setting for each PCI-1756, you
can identify each card in system with different device numbers. The default value of
board ID is 0 and if you need to adjust it to other value, please set the SW1 by refer-
ring to Table 3.1.
Default Setting is 0.
Table 3.1: Board ID Setting (SW1)
BoardID (dec) Switch Position
* = default 1 (ID3) 2 (ID2) 3 (ID1) 4 (ID0)
0ONONON ON
1ONONON OFF
2ONONOFF ON
3ONONOFF OFF
4ONOFFON ON
5ONOFFON OFF
6ONOFFOFF ON
7ONOFFOFF OFF
8 OFF ON ON ON
9 OFF ON ON OFF
10 OFF ON OFF ON
11 OFF ON OFF OFF
12 OFF OFF ON ON
13 OFF OFF ON OFF
14 OFF OFF OFF ON
15 OFF OFF OFF OFF
