20 SIMB-982 User Manual
Chapter 2 Connecting Peripherals
2.5 ATX Power Connector (ATXPWR1, ATXPWR_12V1)
2.6 CPU Fan Header (CPUFAN1)
If a fan is used, this connector supports cooling fans of 500 mA (6 W) or less.
Note! 1. Please connect the ATXPWR_12V1 connector with the PSU ATX 12V
4pin (or 8pin) connector.
2.
For a fully configured system, we recommend that you use a power
supply unit (PSU) that complies with ATX 12V Specification 2.0 (or
later version) and provides a minimum power of 180 W.
