46 SIMB-982 User Manual
Appendix A I/O Pin Assignments
A.13 Audio Amplifier Output Pin Header (JAMP1)
Pin Signal
1
2
3
4
AMP_L-
AMP_L+
AMP_R-
AMP_R+
