SIMB-982 User Manual 53
A.21 8-bits General Purpose IO Pin Header (GPIO1)
Pin Signal Pin Signal
1 GPIO0 2 GPIO4
3 GPIO1 4 GPIO5
5 GPIO2 6 GPIO6
7 GPIO3 8 GPIO7
9+5V 10GND
