44 SIMB-982 User Manual
Appendix A I/O Pin Assignments
A.8 USB3.0 Connector (USB3_1234)
A.9 HD Analog Audio Interface Connector (AUDIO1)
Pin Signal
1 MIC IN
2LINE OUT
Pin Signal Pin Signal
11
VBUS
21
VBUS
12
D-_1
22
D-_2
13
D+_1
23
D+_2
14 GND 24 GND
15
RX-_1
25
RX-_2
16
RX+_1
26
RX+_2
17 GND 27 GND
18
TX-_1
28
TX-_2
19 TX+_1 29 TX+_2
31 VBUS 41 VBUS
32 D-_3 42 D-_4
33 D+_3 43 D+_4
34
GND
44
GND
35 RX-_3 45 RX-_4
36 RX+_3 46 RX+_4
37
GND
47
GND
38 TX-_3 48 TX-_4
39 TX+_3 49 TX+_4
3
LINE IN
