TPC-31/61 User Manual 6
1.4 Dimensions and Cutout
 Weight:
TPC-31T: 0.25 kg (0.55 lbs)
TPC-61T: 0.8 kg (1.76 lb)
 Dimensions (WxHxD):
TPC-31T: 120.79 x 85.5 x 26.5 mm (4.76" x 3.37" x 1.04")
TPC-61T: 195 x 148 x 44.4 mm (7.68" x 5.83" x 1.75")
 Cutout:
TPC-31T: 115 x 79.5 mm
TPC-61T: 189 x 142 mm
Figure 1.4 TPC-31T Dimensions and Cutout
Figure 1.5 TPC-61T Dimensions and Cutout
