TPC-31/61 User Manual 60
F.1 TPC-31T Component construction
F.1 .1 EAMB-2201 Top side
F.2 Jumper Setting DIP Switch
SW6 RS-232 /RS485 Selection
RS-232 Setting
RS-485 Setting
SW6.5 Terminal
OFF (No Terminal)
