USM-110 User Manual 2
1.1 Introduction
USM-110 is an ultra-compact digital signage player that delivers high-performance
graphics and supports H.265-encoded native 4K content at 60fps as well as dual
FHD video output. The system’s ultra-compact, fanless design and support for
diverse mount options ensures easy installation in a wide range of environments.
Moreover, USM-110 is integrated with Advantech’s WISE-Paas/SignageCMS digital
signage management software, which allows users to layout, schedule, and dispatch
signage content to USM-110 over the Internet. This enables remote delivery of
diverse high-resolution multimedia to multiple client devices simultaneously.
1.2 Specifications
1.2.1 General Specifications
USM-110 USM-110 Delight
System CPU
ARM® Cortex®-A17 RK3288 quad-core processor
(1.6 GHz)
Graphics
GPU Mali-T764
Graphics Engine OpenGL ES 1.1/1.2/3.0, OpenCL 1.1, DirectX 11
Memory Capacity 2 GB onboard DDR3L (1333 MHz)
Storage
Flash 16 GB of onboard eMMC 8 GB of onboard eMMC
Extension Micro SD (up to 32 GB)
Multimedia Display Resolution
HDMI 1: Up to 4K (3840 x 2160 resolution)
(default 1080P: 1920 x 1080)
HDMI 2: 1920 x 1080 N/A
I/O
HDMI 2 1
LAN 1 x 10/100/1000 Mbps
Serial Port 1 (RS-232/485/422 via jumper) N/A
USB 2.0 4 1
OTG USB 1
Audio 1
Reset 1
LED Indicators
1 x Power
1 x Wireless Network
DC-In 1
Expansion
Micro SD Card 1
M.2 2230 1 (for optional Wi-Fi module)
Mini PCIe 1 (for optional 4G module) N/A
Mechanical
Dimensions
(L x W x H)
156 x 112 x 28 mm/6.14 x 4.41 x 1.10 in
Weight 0.43 kg/0.94 lb
Power
Input Rating
12V/3A (36W power adapter);
IEEE 802.3at/30W
1
Power
Consumption
Typical 15W
Max. 25W
Installation Mount Options VESA (75 x 75), wall, desktop, pole, magnet, DIN rail
