Advantech USM-110 User Manual

USM-110 User Manual 8
2.3.2 Wall Mount Installation
Step 1.Pull out the two side wings (A) at the rear of the device.
Step 2.Use four screws to affix the device to the wall via the screw holes of the two
side wings.
2.3.3 VESA Mount Installation
1. Using four screws, attach the mount bracket to the VESA (75x75) mount
2. Attach the device to the mount bracket following the “Module Assembly” steps
outlined previously.
2.3.4 Pole Mount Installation
Step 1.Affix the mount bracket to the pole using cable ties (see above illustrations).
Step 2.Attach the device to the mount bracket following the “Module Assembly” steps
outlined previously.
