USM-110 User Manual
Chapter 2
Installation
Step 4.
Insert an antenna cable int
o the module (see the image below for re
ference).
Step 5.
Remove the two rubber plugs tha
t
cover the antenna holes.
A
ttach the
antenna conne
ct
ors.
Insert antenna cable here
Fixed screw
Wi-Fi module
M.2 slot
Mini PCIe slot
4G module
Insert antenna cable here
Fixed screw
18
20
