USM-110 User Manual 16
Table 2.7: JSETCOM4 COM4 RS-232/422/485 Mode Select 2
Setting Function
(5-6) (7-9) (8-10) (13-15) (14-16) RS-232 Mode (default)
(3-4) (9-11) (10-12) (15-17) (16-18) RS-422 Mode
(1-2) (9-11) (10-12) (15-17) (16-18) RS-485 Mode
