Appendix A Pin Assignments
Table A.28: M2M1(H):M.2_2280
Part Number 1654012187-02
Footprint NGFF_75P_AS0BC21-S85BM-7H
Description NGFF 75P 0.5mm 90D(F) H=8.5mm SMD 2E0BC21-S85BM-7H
Pin Pin name
1,3,9,15,21,27 GND
33,39,45,51 GND
57,71,73,75,H4 GND
5,17,29,41 PERN
7,19,31,43 PERP
11,23,35,47 PETN
13,25,37,49 PETP
2,4,12,14,16 3.3V
18,70,72,74 3.3V
49 SATA1_C_TX+
47 SATA1_C _TX-
43 SATA1_C _RX-
41 SATA1_C _RX+
55 CLK5_M2M+
53 CLK5_M2M-
50 M2_2280_RST#
52 M2_2280_CLKREQ#
54 M2_2280_WAKE#
68 CLK32K_M2_2280
6,8,20,22,24,26 NC
28,30,32,34,36 NC
40,42,44,46 NC
48,56,58 NC
