UTC-318 User Manual 54
Table A.29: CN23(D),CN17(EFG):LAN1/LAN2
Part Number 1652003274
Footprint RJ45_28P_RTB-19GB9J1A
Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A
Pin Pin name
Table A.30: CN11(H):LAN1/LAN2
Part Number 1652006625-01
Footprint RJ45_28P_RTB-19GB9J4A
Description PHONE JACK RJ45 28P 2.54mm DIP RTB-19GB9J4A
Pin Pin name
