English 23
PRODUCT
DESCRIPTION
1
4
5
7
6
3
8 9 10
2
11 12
Image 1
1. Reversing camera with connecting cable and
plug to connect to the transmitter
2. Infrared LEDs
3. LCD monitor
4. Radio transmitter with connector cable and
socket to the camera, including connector cable
with a red and black cable for connecting the
transmitter to the reversing light
5. Monitor cable with 12 V car plug
6. Cable ties for securing the transmitting equip-
ment
7. Mounting brackets
8. Gasket as edge trim for the cable gland bore
9. Clamped connections for connecting to reversing
light wires
10. Thread screws for attaching the camera to the
mounting bracket
11. Clamping nuts for securing the thread screws
12. LCD monitor retaining strap
After using a car wash, the camera‘s
for this and readjust the camera if
Even if the fuse inside the 12 V plug
camera and wireless transmitter will
-
specialist.
careful so as not to scratch it.
when installing the backup camera
short circuit and burns!
Run the cables so as not to cause
tripping hazards and the cables
with sharp edges! Do not run cables
across hot surfaces!
