ADJUSTMENT OF STITCH LENGTH
There are nine setting adjustments which can be made from 1.0 to 5.0 mm.
Most overlock work is done with a basic stitch length setting of 2.5-3.5 mm.
[ STITCH LENGTH SETTING ]
Stitches Stitch length
Regular seaming
Narrow seaming
Rolled edging
Picot edging
2.0 – 5.0 mm
3.0 mm (Standard Setting)
1.0 - 2.0 mm
1.0 - 2.0 mm
3.0 - 4.0 mm
Stitch length
adjustment knob (lnner dial)
