AEG 3500 - THREE THREAD OVERLOCK STITCH

( 22 )
THREE THREAD NARROW AND WIDE OVERLOCK
STITCH
This machine is a 3/4 thread convertible
overlock.
Remove either the right or left needle. Your
machine is now ready for use as a 3-thread
overlock.
Refer to "CHANGING THE NEEDLE".
Using the needle on the right only, the stitch
width is 4 mm (0.16").
Using the needle on the left only, the stitch
width is 6 mm (0.24").
Hexagon wrench key
Back side
Front side
Front side
6 mm (0.24”)
4 mm (0.16”)
