( 29 )
CLEANING AND LUBRICATING
Warning: When cleaning the machine or changing its lamp, disconnect it from
the mains. You avoid accidents through electric shock.
To keep your machine running smoothly ; it is necessary to clean using the brush from the
accessory box now and then.
This machine requires very little lubrication as the main components are made of special materials.
Occassionally, lubricate only the points illustrated.
SPECIFICATION OF MACHINE
Description Specification
Number of threads
4 or 3
Number of needles
2 or 1
Sewing speed
1300
± 200 r.p.m
4 - thread………..6 mm
Stitch width
3 - thread………..6 mm or 4 mm
Stitch length
1 ~ 5.0 mm
Lift of presser foot
4.0 mm
HA × 1 No. 11-14
Needles
130/ 705H No. 75 - 90
Dimentions
285 mm ( W) × 285 mm (D) × 291 mm (H)
Weight
6 kg (approx. 15 1bs.)
