Putting the door glass panels back
1. Slide the door glass panels one by one at
an angle from above into the door panel
at the bottom edge of the door and let
them slide down.
Insert the two smaller panels first, followed by
the largest.
2. Take hold of the door cover (B) on the
sides, place on the inside of the door edge
and attach the door cover (B) to the door's
upper edge.
There is a guiding track (C) on the open side of the
door cover (B). Insert this between the outer door
panel and the guiding bracket (D). The clip seal (E)
must be snapped in.
B
C
D
E
34
Care and cleaning
