AEG L7WC8632BI User Manual

The appliance must be level and stable.
CAUTION!
Do not put cardboard, wood
or equivalent materials below
the appliance feet to adjust
the level.
3.6 Hose and cable connection
1100 mm 1450 mm
960 mm1230 mm
900 mm
1360 mm
max 1000 mm
min. 600 mm
max 1000 mm
min. 600 mm
The inlet hose
1. Remove the inlet hose from inside the
drum.
2. To connect the water inlet hose towards
the proper direction and with the proper
inclination, check the position of the water
tap before connecting it to the back of the
appliance.
Make sure the hose is nor
kinked, squashed but neither
tensed.
ENGLISH 11

AEG L7WC8632BI Specifications

General

Door hinge	Left
Drum volume	52 L
Loading type	Front-load
Product color	White
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Built-in
Annual water consumption washing	11200 L
Annual energy consumption washing	194 kWh
Annual water consumption washing & drying	23000 L
Annual energy consumption washing & drying	1060 kWh
Drying capacity	84 kg
Washing capacity	8 kg
Residual moisture	44 %
Maximum spin speed	1600 RPM
Noise level (spin)	70 dB
Noise level (wash)	46 dB
Noise level (drying)	52 dB
Inlet hose length	1.5 m
Outlet hose length	1.4 m
Connected load	2000 W
AC input voltage	230-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Energy consumption washing per cycle	0.97 kWh
Water consumption washing & drying per cycle	- L
Energy consumption washing & drying per cycle	5.3 kWh

Weight and Dimensions

Depth	540 mm
Width	596 mm
Height	819 mm
